Specification

Model: KXZ-100B

Place of origin: China

Technical specifications

●Speed:30-100box/min

●Box Thickness range: 250-350g/m2 (according to its size to confirm)

●Box Size Range:Length:70-220mm

Width:14-90mm

Height:14-65mm

(can do custom designed)

Compressed air

●Working pressure:≧0.6mpa

●Air consumption: 120-160L/min

●Power supply:220V 50Hz

●Motor Power:1.5KW

●Machine dimension (L×w×H):3100×1100×1900mm

●Machine weight: Appro 1500KGS

Standard features

● Touch Screen HMI controls

● PLC programme

● Japan Omron electric parts (inverter, PLC,touch screen...)

● Germany sick photocell

● Vacuum assisted pre-break

● various size are avaliable in machine within machine size range

● without product, carton will be not sucked down

● Auto display trouble, alarm and count finished product

● Overload protection

Optional features

●Bottle feeder/Blister feeder (double function)

● auto conveyor

(connect our machine with your present machine to be whole automatic line)

● hot melt glue (can be american nordson, dynatec, spain meler, switzerland robatech)

●other brand like simens (inverter, PLC, touch screen)

● Print batch number or date on carton box
